Aluminum double-hole terminal（Two-hole aluminum terminal，Aluminum nose，Double-eye aluminum terminal ，Double-hole aluminum wire lug）

Product Features

1. Strong anti-corrosion ability
The shell is usually made of aluminum alloy, and some products are treated with tin plating and other surface treatments, which have strong oxidation resistance and corrosion resistance, and can be used in harsh environments for a long time without damage.
2. Convenient installation
Generally, the installation can be completed only by inserting the aluminum wire into the hollow part of the terminal, and then using the matching terminal pliers and other tools for pressing operation.
The process is simple and fast, without complex tools and skills.
3. Various specifications
It can be divided into various specifications according to the cross-sectional area of the adapter wire, ranging from the model with a smaller cross-sectional area suitable for low-power circuits to the model with a larger cross-sectional area suitable for high-voltage distribution and other high-current scenarios, which can meet different electrical connection needs.

Product Advantages

1. Good conductivity
Aluminum itself has good conductivity, although its conductivity is lower than copper, but the aluminum terminal can meet certain current transmission requirements through reasonable design and process, such as the use of high-quality aluminum, optimized structure, etc., with a large load.
2. Reliable connection
The connection with the main cable is usually in the way of line pressing, which does not damage the conductor, can form a large enough extrusion on the conductor, has reliable contact, strong anti-loose and anti-seismic functions, and can effectively avoid the problem of loose connection caused by vibration and other reasons.

Functional Features

1. Power distribution system
Such as the connection of aluminum cables with switches and instruments in distribution boxes and cabinets.
2. Building electricity
terminal connection of aluminum conductors such as wall sockets and lamps in residential and commercial buildings.
3. Industrial equipment
Aluminum wire power supply or signal access of motors, frequency converters, control cabinets and other industrial equipment.
4. Electrical field of low voltage
Such as the connection and branching of aluminum conductors in junction boxes and terminal blocks.

Specifications


Type No	D	d	L1	L	A	L2	L3	Aperture diameter
DL2-35	12	8.5	36	100	22	50	20	10.5
DL2-50	14	9.8	40	106	22	51	20	10.5
DL2-70	16	11.5	44	118	28	58	25	10.5
DL2-95	18	13.5	47	126	28	59	25	10.5
DL2-120	20	15	49	138	34	65	30	12.5
DL2-150	22	16.5	52	140	34	65	30	12.5
DL2-185	25	18.5	56	152	40	71	35	12.5
DL2-240	27	20.5	60	158	40	71	35	12.5
DL2-300	30	23	62	180	50	85	40	14.5
